HFO-1234ze is an energy-efficient, ultra-low GWP refrigerant alternative to R-134a in air-cooled and water-cooled chillers for supermarkets and commercial buildings, as well as in other medium temperature applications such as heat pumps, refrigerators, vending machines and CO2 cascade systems in commercial refrigeration. Its GWP of less than 1 is 99.9% lower than R-134a.
Product Description
HFO-1234ze is an ideal substitute for R-134a. The chemical structure of pure fluids contains a carbon-carbon double bond which is a key feature facilitating the low global warming characteristic. These molecules also have low atmospheric lifetimes.
It is trans-1,3,3,3-tetrafluoroprop1-ene to which ASHRAE Standard 34 has assigned the nomenclature of HFO-1234ze. The suffix (E) indicates that it is an isomer.
Typical Applications
Ø Refrigerant
Ø Aerosol propellants
Ø Foaming agent
Physical properties
HFO-1234ze |
Chemical Name | trans-1,3,3,3-Tetrafluoroprop-1-ene |
Molecular Formula | CF3CH=CHF |
Appearance | Colourless |
Ozone Depletion Potential (ODP-R11=1) | 0 |
Global Warming Potential rev 5th IPCC(GWP CO2=1) | <1 |
ASHRAE Std. 34 Safety Classification | A2L |
Flammability Limits – ASTM E681-04 @ 21ºC | Non Flammable |
Flammability Limits – ASHRAE 34 @ 100ºC | 7% – 12% (by volume) |
Units | SI |
Molecular weight | 114 kg/mol |
Boiling point at 101.3 kPa | -18.95°C |
Freezing point at 101.3 kPa | -156°C |
Critical temperature | 109.4°C |
Critical pressure | 36.36 bar |
Critical volume | 0.00204 m3/kg |
Critical density | 489 kg/m3 |
Vapour density at boiling point | 5.71 kg/m3 |
Liquid density | 1293 kg/m3 |
Liquid heat capacity at 25°C | 1.383 kJ/kg °K |
Vapour heat capacity at 25°C | 0.9822 kJ/kg °K |
Heat of vaporisation at boiling point | 195.4 kJ/kg |
Vapour pressure at 25°C | 498.6 kPa |
Liquid thermal conductivity at 25°C | 0.0781 W/m °K |
Vapour thermal conductivity at 25°C | 0.0136 W/m °K |
Liquid viscosity at 25°C | 199.4 μPa sec |
Vapour viscosity at 25°C | 12.2 μPa sec |
% Volatiles by volume | 100 |
Solubility of HFO-1234ze(E) in water | 0.037 wt.% |
