Product Name: Extrusion Grade PVDF Resin
Molecular Formula：（-CF2 - CH2 -）n
Product Usage：
RC-7010：This product is an emulsion extrusion grade PVDF resin produced by our company, which is a medium molecular weight, semi-crystalline fluoropolymer homopolymerized by the emulsion method of vinylidene fluoride. It has the advantages of excellent high temperature resistance, chemical corrosion resistance, ultraviolet resistance, high insulation and self-extinguishing of fluororesin. It is mainly used to produce PVDF products (pipes, plates, rods, etc.) by extrusion or molding process.
RCS-7010：This product is an suspended extrusion grade PVDF resin produced by our company, which is a medium molecular weight, semi-crystalline fluoropolymer homopolymerized by the emulsion method of vinylidene fluoride. It has the advantages of excellent high temperature resistance, chemical corrosion resistance, ultraviolet resistance, high insulation and self-extinguishing of fluororesin. It is mainly used to produce PVDF products (pipes, plates, rods, etc.) by extrusion or molding process.
RCS-7012：This product is an suspension extruded PVDF resin produced by our company, which is a medium to high molecular weight, semi-crystalline fluoropolymer homopolymerized by the suspension method of vinylidene fluoride. It has the advantages of excellent high temperature resistance, chemical corrosion resistance, ultraviolet resistance, high insulation and self-extinguishing of fluororesin. It is mainly used to produce PVDF products (pipes, plates, rods, fishing lines, etc.) by extrusion process.
Physical and Chemical Properties: White Powder, Melting Point 165-175℃, Standard Specific Gravity 1.75-1.79. The product is placed under outdoor conditions for a long time, which do not become brittle and crack. It has excellent rigidity, hardness, creep resistance and fatigue resistance.
Packaging, Storage and Transportation: The product should be stored in a clean and dry warehouse daily to prevent from the impurities. This product is non-toxic and harmless at room temperature. Attention should be paid to avoid processing temperature over 350 ℃, otherwise the product can decompose toxic gases under high temperature.
Packing Specification: The product is mainly packed in two-layer polyethylene plastic bag, carton box and ton bag for customer to choose.
Technical Parameters：
Item | Spec |
RC-7010 | RCS-7010 | RCS-7012 |
Appearance | Powder F: white powder Granule L: white translucent granule | Powder F: white powder Granule L: white translucent granule | Powder F: white powder Granule L: white translucent granule |
Relative Density，g/ | 1.75-1.79 | 1.75-1.79 | 1.75-1.79 |
Melting Point, ℃ | 165-175 | 170-175 | 170-175 |
Melt Flow Indicator, g/10min | 3-8 (5kg) | 3-8 (5kg) | 9-14 (21.6kg) |
Tensile Strength, (23℃, 50mm/min) Mpa. | ≥25 | ≥25 | ≥25 |
Elongation at Break, ( 23℃, 50mm/min) % | ≥20 | ≥20 | ≥20 |
Shore Hardness Type D | 70 | 70 | 70 |
Moisture Content, % | ≤0.1 | ≤0.1 | ≤0.1 |
Thermal Decomposition Temperature, ℃ | >375 | >375 | >375 |
